project name |
parameter |
|
Maximum test force |
1000kN |
|
Test force indication relative error |
±1% of the indicated value |
|
Test force measurement range |
2% to 100% of the maximum test force |
|
Constant velocity stress control range (N/mm 2 ·S -1 ) |
2~60 |
|
Constant velocity control range |
0.00025/s~0.0025/s |
|
Constant velocity displacement control range (mm/min) |
0.5~50 |
|
Clamping method |
Hydraulic clamping |
|
Round specimen clamping diameter range mm |
Φ1 3 ~Φ 60 |
|
Flat specimen clamping thickness range mm |
0~40 |
|
Flat specimen clamping width mm |
80 |
|
Maximum tensile test space mm |
650 |
|
Maximum compression test space mm |
600 |
|
Control cabinet dimensions mm |
1100×620×850 |
|
Mainframe dimensions mm |
900 × 750 × 2 300 |
|
Motor power kW |
2.3 |
|
Host quality kg |
5600 |
|
Column clearance (mm) |
580 |
|
Upper and lower platen size mm |
205*205 |
|
Curved stick spacing mm |
450 |
|
Bending rod width mm |
140 |
|
Allowable bending mm |
100 |
|
Maximum piston stroke mm |
200 |
|
Piston maximum moving speed mm/min |
About 60 |
